1. General Information

• Model Name: Dasscom DS-Q10 (or SQ-10 / SQ-10 Basic)

• Product Type: SIP-Enabled IP Network Square Speaker

• Primary Application: Public Address (PA), Background Music, 2-Way Intercom

• Installation Mode: Surface-mounted or Flush-mounted (Wall or Ceiling)

• Ideal Environments: Classrooms, Libraries, Offices, Hospitals, Corridors

2. Audio Specifications

• Rated Power: 10 Watts (RMS)

• Amplifier Type: Class D Topology (Built-in)

• Frequency Response: 70 Hz – 20 kHz

• Sensitivity: 91 dB (1m/1W)

• Max SPL: 101 dB

• Audio Codecs: G.711 (A-law/U-law), G.722, Opus (HD Audio)

• Microphone: Built-in electret microphone for full-duplex 2-way communication (Intercom)

3. Network & Connectivity

• Network Port: 1× RJ45 (10/100 Base-T)

• Protocol Support: SIP (RFC3261), HTTP, TCP/IP, UDP, RTP, RTCP, MQTT, ICMP, DHCP, NTP, DNS

• IP Addressing: Static IP or DHCP

• Security: Password protection, IP filtering, Digest authentication

• SIP Accounts: Compatible with standard SIP servers (Asterisk, 3CX, Grandstream, etc.) and Dasscom X10 Gateway

4. Power Requirements

• Power over Ethernet: PoE (IEEE 802.3at / PoE+ compliant)

• External Power (Optional): 12V – 24V DC input (as backup or if PoE is unavailable)

5. Physical & Mechanical

• Shape: Square Cabinet

• Material: Cold-rolled steel (Metal housing)

• Finish: Textured white epoxy powder coating

• Dimensions (Approx): $180 \text{ mm} \times 180 \text{ mm} \times 60 \text{ mm}$ (Compact Square)

  • Note: Verify exact dimensions with the supplier as “Square” models vary between 180mm and 280mm depending on the batch/revision.

• Weight: ~1.2 kg to 1.5 kg

• Operating Temperature: -20°C to +50°C

• Humidity: 10% – 95% (Non-condensing)

6. Smart Features

• Reset Button: Integrated hardware reset key (Hold 3s to announce IP; 10s to factory reset)

• Peripheral Support: Dry contact support for external buttons or strobes (model dependent)

• Remote Management: Web-based GUI for configuration and firmware upgrades
