Key Specifications

• Video output: 4K UHD (3840 × 2160) @ 30 Hz via HDMI 1.4b or USB-C DisplayPort 1.2 (USB-C DisplayPort is supported only in Gen2 models) assets.barco.com+1

• USB ports: Front: 1× USB-A and 1× USB-C. On Gen2, these are USB-3.0 capable. barco.com+2Auvix+2

• Network & Wireless:

  • 1× Ethernet LAN (1 Gbit) assets.barco.com+1

  • WiFi: IEEE 802.11 a/g/n/ac (2.4 GHz & 5 GHz) plus Bluetooth/IEEE 802.15.1 for Button link. barco.com+1

• Max wireless “reach” between ClickShare Button (or base) and base unit: approx. 30 m (100 ft) in typical conditions. assets.barco.com+1

• BYOD / Screen-mirroring protocols: AirPlay, Google Cast, Miracast supported. assets.barco.com

• Maximum simultaneous sources on screen: 1 (for CX-20) barco.com

• Authentication / Security:

  • Stand-alone mode: WPA2-PSK assets.barco.com

  • Network integration mode: WPA2-PSK or IEEE 802.1X using the ClickShare Button. assets.barco.com

• Dimensions & weight: 34 mm (H) × 135 mm (W) × 135 mm (D); Weight approx. 900 g. barco.com+1

• Operating environment:

  • Operating temperature: 0 °C to +40 °C assets.barco.com

  • Storage: –20 °C to +60 °C assets.barco.com

• Power consumption: Typical operational ~5-10 W, maximum ~24 W. assets.barco.com

• Anti-theft: Kensington lock slot included. barco.com

• Warranty: Standard 1 year; with registration and SmartCare plan, up to 5 years coverage.
