Key Specifications

• Video Output: 4K UHD (3840×2160) @ 30 Hz via HDMI 1.4b or USB-C DisplayPort 1.2 (Gen2 supports USB-C DisplayPort) barco.com+3assets.barco.com+3exertisproav.de+3

• USB Ports (front): 1× USB-A and 1× USB-C — in Gen2 models these are USB 3.0 capable for front-ports. barco.com+1

• Network & Wireless: 1× Ethernet LAN (1 Gbit) + WiFi (2.4 GHz & 5 GHz) channel support (IEEE 802.11 a/g/n/ac) and Bluetooth/IEEE 802.15.1 for Buttons. Reach up to ~30 m (100 ft) between Button & base unit. assets.barco.com+1

• BYOD & Cast Protocols: Supports AirPlay, Google Cast, Miracast for screen-mirroring from laptop, smartphone or tablet. yyst-global.com+1

• Maximum simultaneous sources: 1 user on screen for C-5. assets.barco.com+1

• Operating Conditions: 0 °C to +40 °C; Storage: -20 °C to +60 °C. Humidity and altitude specs as per standard. assets.barco.com

• Noise / Power Consumption: Operational 5-10 W typical, max ~24 W. Noise max ~25 dBA @ 0-30 °C. assets.barco.com+1

• Dimensions & Weight: 34 mm (H) × 135 mm (W) × 135 mm (D); Weight approx. 900 g. assets.barco.com+1

• Security / Management: Kensington lock slot for anti-theft; fully cloud-manageable via Barco XMS; supports network integration mode (IEEE 802.1X) and standalone mode (WPA2-PSK). assets.barco.com+1

• Warranty: 1-year standard; up to 5 years via registration & SmartCare package.
